Configuration Prog. no. Level Standard value
Hot water separate circuit
Off | On
5736 E Off
Optg action HW div valve
Position on CH | Position on HW
5737 E Position on CH
Ctrl boiler pump/HW valve
All requests | Request CH1/HW only
5774 E All requests
Boiler pump at DHW
Off | On
5775 E On
Solar controlling element
Charging pump | Diverting valve
5840 E Diverting valve
External solar exchanger
Commonly | Hot water storage tank | Buffer storage tank
5841 E Commonly
Combi storage tank
No | Yes
5870 E No
Relay output QX1
None | Circulating pump Q4 | El imm heater HW K6 | Collector pump Q5 | Cons
circuit pump VK1 Q15 | Boiler pump Q1 | Alarm output K10 | heating pump CH3
Q20 | Cons circuit pump VK2 Q18 | System pump Q14 | Heat gen shutoff valve
Y4 | Solid fuel boiler pump Q10 | Time setting 5 K13 | Buffer return valve Y15 |
Solar pump ext exch K9 | Solar ctrl elem buffer K8 | Solar ctrl elem swi pool K18
| Swimming pool pump Q19 | Cascade pump Q25 | St tank transfer pump Q11 |
Hot water mixing pump Q35 | HW interm circ pump Q33 | Heat request K27 |
heating pump CH1 Q2 | heating pump CH2 Q6 | Hot water ctrl elem Q3 | Status
output K35 | Status information K36 | Flue gas damper K37 | Fan shutdown K38
5890 C None
Relay output QX2
See
Parameters see Relay output QX1 (prog. no. 5890)!
5891 C None
Relay output QX3
See
Parameters see Relay output QX1 (prog. no. 5890)!
5892 C Hot water ctrl elem
Q3
Sensor input BX1
None | Hot water sensor B31 | Collector sensor B6 |HW circulation sensor B39 |
Buffer sensor B4 | Buffer sensor B41| Common flow sensor B10 | Solid fuel
boiler sensor B22 |HW charging sensor B36 |Buffer sensor B42 | Common
return sensor B73 | Cascade return sensor B70 | Swimming pool sensor B13 |
Solar flow sensor B63 | Solar return sensor B64
5930 C Collector sensor B6
Sensor input BX2
See
Parameters see Sensor input BX1 (prog. no. 5930)!
5931 C Hot water sensor
B31
Sensor input BX3
See
Parameters see Sensor input BX1 (prog. no. 5930)!
None | Hot water sensor B31 | Collector sensor B6 | HW charging sensor B36
5932 C Buffer sensor B4
Function input H1
None | Optg mode change CHs+HW | Optg mode changeover HW | Optg mode
changeover CHs | Optg mode changeover CH1 | Optg mode changeover CH2 |
Optg mode changeover CH3 | Heat generation lock | Error/alarm message |
Consumer request VK1 | Consumer request VK2 | Release swimpool source
htg | Excess heat discharge | Release swi pool solar | Operating level HW |
Operating level CH1 | Operating level CH2 | Operating level CH3 | Room
thermostat CH1 | Room thermostat CH2 | Room thermostat CH3 | Hot water
thermostat | Pulse count | Checkb sign flue gas damper | Start prevention |
Consumer request VK1 10V | Consumer request VK2 10V | Preselected output
10V
5950 C None
