Configuration of extension modules Prog. no. Level Standard value
Relay output QX21 module 1
None | Circulating pump Q4 | El imm heater HW K6 | Collector pump Q5 | Cons
circuit pump VK1 Q15 | Boiler pump Q1 | Alarm output K10 | heating pump CH3
Q20 | Cons circuit pump VK2 Q18 | System pump Q14 | Heat gen shutoff valve
Y4 | Solid fuel boiler pump Q10 | Time setting 5 K13 | Buffer return valve Y15 |
Solar pump ext exch K9 | Solar ctrl elem buffer K8 | Solar ctrl elem swi pool K18
| Swimming pool pump Q19 | Cascade pump Q25 | St tank transfer pump Q11 |
Hot water mixing pump Q35 | HW interm circ pump Q33 | Heat request K27 |
heating pump CH1 Q2 | heating pump CH2 Q6 | Hot water ctrl elem Q3 | Status
output K35 | Status information K36 | Fan shutdown K38
7301 C None
Relay output QX22 module 1
See
Parameters see Relay output QX21 module 1 (prog. no.
7301)!
7302 C None
Relay output QX23 module 1
See
Parameters see Relay output QX21 module 1 (prog. no.
7301)!
7303 C None
Sensor input BX21 module 1
None | Hot water sensor B3 | Hot water sensor B31 | Collector sensor B6 | HW
circulation sensor B39 | Buffer sensor B4 | Buffer sensor B41 | Common flow
sensor B10 | Solid fuel boiler sensor B22 | HW charging sensor B36 | Buffer
sensor B42 | Common return sensor B73 | Cascade return sensor B70 |
Swimming pool sensor B13 | Solar flow sensor B63 | Solar return sensor B64
7307 C None
Sensor input BX22 module 1
See
Parameters see Relay output QX21 module 1 (prog. no.
7307)!
7308 C None
Function input H2 module 1
None | Optg mode change CHs+HW | Optg mode changeover HW | Optg mode
changeover CHs | Optg mode changeover CH1 | Optg mode changeover CH2 |
Optg mode changeover CH3 | Heat generation lock | Error/alarm message
Consumer request VK1 | Consumer request VK2 | Release swimpool source
htg | Excess heat discharge | Release swi pool solar | Operating level HW |
Operating level CH1 | Operating level CH2 | Operating level CH3 | Room
thermostat CH1 | Room thermostat CH2 | Room thermostat CH3 | Hot water
thermostat| Limit thermostat CH | Start prevention | Consumer request VK1 10V
| Consumer request VK2 10V | Preselected output 10V
7311 C None
Contact type H2 module 1
NC | NO
7312 C NO
Voltage value 1 H2 module 1 7314 E 0.5
Funct value 1 H2 module 1 7315 E 0
Voltage value 2 H2 module 1 7316 E 10
Funct value 2 H2 module 1 7317 E 100
Function input H21 module 1
None | Optg mode change CHs+HW | Operating level HW | Optg mode
changeover CHs | Optg mode changeover CH1 | Optg mode changeover CH2 |
Optg mode changeover CH3 | Heat generation lock | Error/alarm message |
Consumer request VK1 | Consumer request VK2 | Release swimpool source
htg | Excess heat discharge | Release swi pool solar | Operating level HW |
Operating level CH1 | Operating level CH2 | Operating level CH3 | Room
thermostat CH1 | Room thermostat CH2 | Room thermostat CH3 | Hot water
flow switch | Hot water thermostat | Limit thermostat CH | Start prevention |
Consumer request VK1 10V | Consumer request VK2 10V | Preselected output
10V
7321 C None
Contact type H21 module 1
NC | NO
7322 C NO
