Configuration of extension modules Prog. no. Level Standard value
Input value 1 H21 module 1 7324 E 0
Funct value 1 H21 module 1 7325 E 0
Input value 2 H21 module 1 7326 E 10
Funct value 2 H21 module 1 7327 E 100
Funct input EX21 module 1
None | Temperature monitor HC
7342 C None
Funct output UX21 module 1
None | Boiler pump Q1 | Hot water pump Q3 | HW interm circ pump Q33 | Heat
ing pump CH1 Q2 | Heating pump CH2 Q6 | Heating pump CH3 Q20 | Collector
pump Q5 | Solar pump ext exch K9 | Solar pump buffer K8 | Solar pump swi
pool K18
7348 E None
Signal output UX21 module 1
10 V | PWM
7350 E PWM
Funct output UX22 module 1
See
Parameters see Funct output UX21 module 1 (prog. no.
7348)!
7355 E None
Signal output UX22 module 1
10 V | PWM
7357 E PWM
Function extension module 2
None | Multifunctional | Temps / mode CH1 | Temps / mode CH2 |Temps /
mode CH3 | Solar HW | Primary contr/system pump
7375 C None
Relay output QX21 module 2
None | Circulating pump Q4 | El imm heater HW K6 | Collector pump Q5 | Cons
circuit pump VK1 Q15 | Boiler pump Q1 | Alarm output K10 | heating pump CH3
Q20 |Cons circuit pump VK2 Q18 | System pump Q14 | Heat gen shutoff valve
Y4 | Solid fuel boiler pump Q10 | Time setting 5 K13 | Buffer return valve Y15 |
Solar pump ext exch K9 | Solar ctrl elem buffer K8 | Solar ctrl elem swi pool K18
| Swimming pool pump Q19 | Cascade pump Q25 | St tank transfer pump Q11 |
Hot water mixing pump Q35 | HW interm circ pump Q33 | Heat request K27 |
heating pump CH1 Q2 | heating pump CH2 Q6 | Hot water ctrl elem Q3 | Status
output K35 | Status information K36 | Fan shutdown K38
7376 C None
Relay output QX22 module 2
See
Parameters see Relay output QX21 module 2 (prog. no.
7376)!
7377 C None
Relay output QX23 module 2
See
Parameters see Relay output QX21 module 2 (prog. no.
7376)!
7378 C None
Sensor input BX21 module 2
See
Parameters see Sensor input BX21 module 1 (prog. no.
7307)!
7382 C None
Sensor input BX22 module 2
See
Parameters see Sensor input BX21 module 1 (prog. no.
7307)!
7383 C None
Function input H2 module 2
See
Parameters see Function input H2 module 1 (Prog. no. 7311)!
7386 C None
Contact type H2 module 2
NC | NO
7387 C NO
