Configuration of extension modules Prog. no. Level Standard value
Voltage value 1 H2 module 2 7389 E 0,5
Funct value 1 H2 module 2 7390 E 0
Voltage value 2 H2 module 2 7391 E 10
Funct value 2 H2 module 2 7392 E 100
Function input H21 module 2
See
Parameters see Function input H21 module 1 (prog. no.
7321)!
7396 C Optg mode change
CHs+HW
Contact type H21 module 2
NC | NO
7397 E NO
Input value 1 H21 module 2 7399 E 0.0
Funct value 1 H21 module 2 7400 E 0
Input value 2 H21 module 2 7401 E 10.0
Funct value 2 H21 module 2 7402 E 100
Funct input EX21 module 2
None | Limit thermostat HC
7417 C None
Funct output UX21 module 2
See
Parameters see Funct output UX21 module 1 (prog. no.
7348)!
7423 E None
Signal output UX21 module 2
10 V | PWM
7425 E PWM
Funct output UX22 module 2
See
Parameters see Funct output UX21 module 1 (prog. no.
7348)!
7430 E None
Signal output UX22 module 2
10 V | PWM
7432 E PWM
Input/output test Prog. no. Level Standard value
Relay test 7700 C No test
Output test P1 7713 C - - - %
PWM signal P1 7714 C
Outside temp B9 7730 C
Hot water temp B3/B38 7750 C
Boiler temp B2 7760 C
Output test UX21 module 1 7780 C
Output signal UX21 module 1
None | Closed (ooo), Open (---) | Pulse | Frequency Hz | Voltage V | PWM %
7781 C None
Output test UX22 module 1 7782 C
Output signal UX22 module 1
See
Parameters see Output signal UX21 module 1 (prog. no.
7781)!
7783 C None
Output test UX21 module 2 7784 C - - - %
Output signal UX21 module 2
See
Parameters see Output signal UX21 module 1 (prog. no.
7781)!
7785 C None
