The type plate includes the following information:
n Manufacturer address
n 'CE'-sign
n Control unit model
n Serial number
n Article number
n Connection values
Fig. 4: Type Plate (Example)
The label affixed to the side of the control unit next to the type plate
provides the operating system's product key.
CAUTION!
If the label with the operating systems's product key is
not readable or damaged, the particular Windows-
licence will be void and can not be renewed. For this
reason, the label has to be treated carefully.
A new operating system's licence can be ordered at
Power Automation (see
Ä
Chapter 9 “Service and
return process” on page 95).
Fig. 5: Windows 7 for Embedded Systems operating system
license
The first CNC Software version, which runs under Windows 7 is
version 3.5.0.0. For compatibility reasons, the folders remain
unchanged for Windows XP systems.
Type Plate
Operating System Product Key
PA 8000 EL CNC control unit
Safety
24.09.2015 | 24
