3.3.1 Digital inputs
3.3.1.1 Input interfaces
Fig. 8: Input bytes
10 Input byte 2 (X46)
11 Input byte 1 (X45)
12 Input byte 3 (X47)
The inputs are grouped in bytes (8 signals).
Overview
PA 8000 EL CNC control unit
Design and function
24.09.2015 | 29
