power automation PA 8000 EL User Manual

Standard Title Requirement Value
IEC / EN 61000-6-2 [...] Immunity standard for industrial
environments
EN 61000-4-2 [...] Electrostatic discharge immunity
[...]
ESD air discharge 8 KV
contact discharge 4 KV
EN 61000-4-3 [...] Radiated, radio-frequency, electro-
magnetic field immunity [...]
HF irradiation 80..1000 MHz 10 V/m
EN 61000-4-4 [...] Electrical fast transient/burst
immunity [...]
power line burst 2 KV
signal data line burst 1 KV
EN 61000-4-5 [...] Surge immunity [...] symmetric 1 KV
asymmetric 2 KV
EN 61000-4-6 [...] Conducted disturbances immunity
[...]
HF power input into the net,
signal/data line
10 V
EN 61000-4-8 [...] Magnetic field immunity [...] magnetic field 50 Hz 30 A/m
EN 61000-4-11 [...] Voltage variations [...] voltage drops and interrupts
Standard Title Requirement Value
EN 61000-3-2: 2006 [...] Limits for harmonic current emis-
sions
all met -
EN 61000-3-3:2008
4.6 Installation guidelines
Electromagnetic compatibility (EMC) refers to the ability of an elec-
trical device to work flawlessly in an electromagnetic environment
without generating or being susceptible to disturbances. All PA
Control units are designed for use in industrial environments and
meet high EMC specifications.
Cabling
n The cabling must be in line groups (high voltage, current
supply, signal and data lines)
n High voltage lines and signal respectively data lines must be
laid in separate channels or bundles
n The signal and data lines have to be routed as near as pos-
sible beside ground areas
Interference Resistance
Net Overtones
Meaning Of EMC
Important Rules For EMC
PA 8000 EL CNC control unit
Technical data
24.09.2015 | 69
