3.3.4 Module 2416 EL LEDs
The 2416 EL module has four LEDs for diagnostic purposes.
Fig. 21: Status LEDs
1 Status
2 Access
3 Bustest
4 Monitor
For a detailed assignment of the LEDs' states see
Ä
Chapter 8.2.1
“Module 2416 EL LEDs” on page 91.
Overview
PA 8000 EL CNC control unit
Design and function
24.09.2015 | 46
