Page #45 background imageLoading...
Page #45 background image
n Pin 1 and 2 are connected internally.
n Pin 4 and 5 are connected internally.
n Reference for all is pin 3 (0 V).
n With pins 1 and/or 2 and pins 4 and/or 5 the output bytes are
supplied separately. The two output bytes can be supplied
independently from each other.
This allows, for example, power to be supplied independently
to each byte in case of an emergency stop.
For proper load balancing across pins, connections to
all available pins per output byte are recommended.
Establish wire connections to both pins 1/2 and 3/4
respectively.
The current limitation of each output is 0.7 - 2.5 A per
pin in case of short circuits.
Consider that the power supply cable for each
output byte has to be chosen accordingly.
Notes
PA 8000 EL CNC control unit
Design and function
24.09.2015 | 45
