3.3.2.2 Output characteristics
Property Value Unit
Number of outputs 16
Max. continuous output DC per pin 1 A
Max. total continuous
output current per byte
4 A
Power dissipation
per pin at 24 V for 0.5 A
0.20 W
Power dissipation
per pin at 24 V for 1.5 A
0.45 W
Output ON delay (typical) 100 μs
Output OFF delay (typical) 200 μs
Watchdog (max.) 64 ms
Short circuit output DC 0.7 - 2.5 A
Delay time current limitation (max.) 2 ms
Isolation by opto coupler
Output ON display LED
External connection 1 terminal block for 8 out-
puts
All outputs are referenced against 0 V (power supply
connector X30, pin 3).
PA 8000 EL CNC control unit
Design and function
24.09.2015 | 41
