Fig. 17: Output status LEDs

The output LEDs are located directly in the output path and there-

fore show the real state of the 24 V outputs.

n If the outputs are ON, the corresponding LEDs are ON.

n If the outputs are OFF, the corresponding LEDs are OFF.

n In case of a short circuit, the output LED is OFF, even if the

output is active.

Output Status LEDs

PA 8000 EL CNC control unit

Design and function

24.09.2015 | 40
