Bulletin No. 3020IM9503R6/98 Power Meter

December 1998 Chapter 4—Installation

Figure 4-2: Mounting power meter on panel with no existing cutout

Template

Panel

1.6875

3.375

4 Holes

0.1875 (5 mm)

1.6875

2" to 4" Hole

51–102

Dual Dimensions:

Inches

Millimeters

Figure 4-3: Panel mount for the power meter display

Note: The dimensions and positions of the 4 display holes shown above are identical for the power meter module.
