Bulletin No. 3020IM9503R6/98 Power Meter
December 1998 Chapter 7—Display Operation
1998 Square D All Rights Reserved 49
➀ PM-620 and PM-650.
➁ The pulse constant parameter is displayed only when the KYZ mode is enabled (KWH, KVAH, or KVARH
energy mode).
Setup Mode
The Setup mode lets you configure the following parameters:
• Protocol
• Device Address
• Baud Rate
• Parity (even or none)
• CT Primary
• CT Secondary
• Voltage Range
• PT Primary
• PT Secondary
• System Type
• Frequency
• Power Demand Interval
➀
• KYZ Mode
• Pulse Constant
➁
• THD/thd
➀
You can also set the date
➀
, time
➀
, master password, and reset password.
