PowerLogic PM-600 User Manual

Bulletin No. 3020IM9503R6/98 Power Meter
December 1998 Chapter 7—Display Operation
 1998 Square D All Rights Reserved 53
YES
NO
Press the Mode
button once.
Press the
Select button to
choose Setup.
Press the Mode
button until “Setup”
is displayed.
Start
Press the Select button
to move to the parameter
to be changed.
Use the arrow
buttons to change
the value.
Do you want
to change
another
parameter?
Do you want
to accept
the changes?
Press
arrow ▲ button.
Press the
Select button.
Power Meter accepts
changes and restarts.
YES
NO
Press the
Select button.
Display returns
to mode list.
Use the arrow
buttons to display the
password. Then press
the
Select button.
Figure 7-3: Power meter setup flowchart
