Bulletin No. 3020IM9503R6/98 Power Meter

December 1998 Chapter 4—Installation

Figure 4-4: Mounting power meter on 35 mm DIN rail

DIN Rail Clip

DIN Rail Hooks

DIN Rail

Side View

After Installation

Side View
