Power Meter Bulletin No. 3020IM9503R6/98
Chapter 7—Display Operation December 1998
54 1998 Square D All Rights Reserved
PERFORMING RESETS
To reset energy, demand
➀
, and min/max
➁
values using the display, follow
these steps:
1. Press the Mode button until “Resets” is displayed.
2. Press the Select button to enter the Resets mode. The display shows the
password prompt.
3. Use the arrow buttons to enter the Reset Password; press the Select button.
4. Press the Select button to find the value you want to reset.
5. Press either arrow key to change from “no” to “yes.”
6. Repeat steps 4 and 5 until all desired resets have been made.
7. After enabling all desired resets, press the Mode button. The display reads
“RESET NOW? NO.”
8. To reject resets, press the Select button once.
9. To accept resets, press either arrow button to change “NO” to “YES.”
Then press the Select button. You’ll see a brief message: “Resetting, Please
Wait…” as the changes are made.
➀ Demand values available on models PM-620 and PM-650.
➁ Min/max values available on model PM-650 only.
