Power Meter Bulletin No. 3020IM9503R6/98
Appendix F—Register List December 1998
88 1998 Square D All Rights Reserved
Reg. No. Register Name Units Range
1247 Minimum Apparent Power, Phase A kVA/Scale Factor E 0 to ±32,767
1248 Minimum Apparent Power, Phase B kVA/Scale Factor E 0 to ±32,767
1249 Minimum Apparent Power, Phase C kVA/Scale Factor E 0 to ±32,767
1250 Minimum Apparent Power, Total kVA/Scale Factor E 0 to ±32,767
1251 Minimum THD/thd Current, Phase A Percent in 10ths 0 to 10,000
1252 Minimum THD/thd Current, Phase B Percent in 10ths 0 to 10,000
1253 Minimum THD/thd Current, Phase C Percent in 10ths 0 to 10,000
1254 Reserved
1255 Minimum THD/thd Voltage, Phase A Percent in 10ths 0 to 10,000
1256 Minimum THD/thd Voltage, Phase B Percent in 10ths 0 to 10,000
1257 Minimum THD/thd Voltage, Phase C Percent in 10ths 0 to 10,000
1258 Reserved
1259 Reserved
1400 Maximum Update Interval In 1000ths of a second 0 to 10,000
1401 Maximum Frequency Hertz/Scale Factor F 4500 to 6600
1402 Reserved
1403 Maximum Current, Phase A Amps/Scale Factor A 0 to 32,767
1404 Maximum Current, Phase B Amps/Scale Factor A 0 to 32,767
1405 Maximum Current, Phase C Amps/Scale Factor A 0 to 32,767
1406 Maximum Current Neutral, Calculated Amps/Scale Factor A 0 to 32,767
1407 Reserved
1408 Reserved
1409 Reserved
1410 Maximum Current Unbalance, Ph. A Percent in 10ths 0 to ±1000
1411 Maximum Current Unbalance, Ph. B Percent in 10ths 0 to ±1000
These registers can be used with POWERLOGIC, Modbus, or Jbus protocols. Although POWERLOGIC
and Jbus protocols use a zero-based register addressing convention and Modbus uses a one-based
register addressing convention, the power meter, when configured for Modbus communications,
automatically compensates
for the Modbus offset of one. Regard all registers as holding registers where a
30,000 or 40,000 offset can be used (e.g., Current, Phase A = 31,003 or 41,003).
PM-650 only.
