Fault-Codes
If the controller detects an error, the controller continues to work with restrictions or stops operation
depending on the error. Depending on how serious the error is, the drive current will be reduced
(machine moves very slowly) or the controller will shut off completely.
The following table describes the error codes and how to correct them.
Note: The Error / Error Action column contains both the error name and the action (s) of the controller
when the error is detected.
Error-Code
Fault und Fault-Action
Possible Causes
Set and Clear Conditions
1,2
Controller Overcurrent
Shutdown Motor
Shutdown Main Contactor
Shutdown EM-Brake
Shutdown Throttle
• External short of phase M1
or M2 motor connections.
• The controller is defective.
The phase current exceeds the
current limit.

Check the connections,
then cycle the keyswitch.
1,3 Current Sensor
Shutdown Motor
Shutdown Main Contactor
Shutdown EM-Brake
Shutdown Throttle
The controller is defective. The controller’s current sensors
have invalid offset readings.
 Cycle the keyswitch.
1,4
Precharge Failed
Shutdown Motor
Shutdown Main Contactor
Shutdown EM-Brake
Shutdown Throttle
•
An external load on the
capacitor bank (Brake+
connection terminal or B+
connection terminal for the
external
contactor model)
prevents the capacitor bank
from charging.
• The controller is defective
The precharge failed to charge
the capacitor bank.
 Cycle the keyswitch.
1,5
Controller Severe Under
temperature
Shutdown Motor
Shutdown Main Contactor
Shutdown EM-Brake
Shutdown Throttle
The controller is operating in an
extremely cold environment.
The heatsink temperature is
below –40°C.

Raise the heatsink
temperature to above
-
40°C, then cycle the
keyswitch.
1,6
Controller Severe Over
temperature
Shutdown Motor
Shutdown Main Contactor
Shutdown EM-Brake
Shutdown Throttle
The controller is operating in an
extremely hot environment.
The heatsink temperature is
above 85°C.

Decrease the heatsink
temperature to below 85°C,
then cycle the keyswitch.
