Page 33 of 49 Instructions/Parts list Multi-Dumper MCE400 updated: 04.2021
9,5 Parameter Mismatch
Shutdown Motor
Shutdown Main Contactor
Shutdown EM-Brake
Shutdown Throttle
Shutdown Vehicle
Two or more parameters are set
to conflicting values.
The controller detects conflicting
parameter values.
 Contact costumer support
9,9
Driver 1
Shutdown Driver 1
• The coil is open or shorted.
• Dirty connector pins for the
controller or the contactor
coil.
•
Bad connector crimps or
faulty wiring.
• Driver overcurrent
The driver is open or shorted.

Address the possible
causes, then cycle the
keyswitch.
9,10 Driver 2
Shutdown Driver 2
10,3 Driver Assignment
Shutdown Driver
A driver output is being used for
two or more functions.
A driver assignment conflict is
detected.
 Resolve the driver conflict,
then cycle the keyswitch.
11,4
EMR SRO
Shutdown Throttle
The emergency reverse switch
was on when the keyswitch was
powered on.
The operator turned the
keyswitch on while the
emergency reverse switch was
on.

Turn off the emergency
reverse switch, then cycle
the keyswitch.
11,8 SW FAULT
Shutdown Motor
Shutdown Main Contactor
Shutdown EM-Brake
Shutdown Throttle
Shutdown Interlock
Shutdown Driver1
Shutdown Driver2
Shutdown Driver3
Shutdown Driver4
Shutdown Driver5
Defective controller. The controller did not power up
correctly.
 Cycle the keyswitch.
11,11
Motor Short
Shutdown Motor
Shutdown EM-Brake
Shutdown Main Contactor
M1 and M2 are shorted
The controller detects M1 and
M2 are shorted when the
interlock is turned on.
 Fix the connections to M1
and M2, then cycle the
keyswitch.
