UPS with Bypass Electrical Installation
34
Powerware
®
9170
+
UPS User’s Guide S Rev B www.powerware.com
NOTE 1
S 110/220 Input, 110/220 Output
S 120/208 Input, 120/208 Output
S 120/240 Input, 120/240 Output
S 100/200 Input, 100/200 Output
S 127/220 Input, 127/220 Output
NOTE 3 NOTE 2
NOTE 3
NOTE 2
NOTE 3
NOTE 3 NOTE 7
NOTE 4
NOTE 5
NOTE 7
NOTE 6
Figure 22. External Bypass Switch (L1, L2, N), Non-Isolated Output, Split-Phase Power Modules
NOTE 2
S 200 Input, 200 Output
S 208 Input, 208 Output
S 220 Input, 220 Output
S 230 Input, 230 Output
S 240 Input, 240 Output
NOTE 1
NOTE 3 NOTE 2
NOTE 3
NOTE 3
NOTE 3 NOTE 7
NOTE 4
NOTE 5
NOTE 7
NOTE 6
Figure 23. External Bypass Switch (L1, L2), Non-Isolated Output, Universal Power Modules
