UPS Electrical Installation
48
Powerware
®
9170
+
UPS User’s Guide S Rev B www.powerware.com
NOTE 3
S 110/220 Input, 110/220 Output
S 120/208 Input, 120/208 Output
S 120/240 Input, 120/240 Output
S 100/200 Input, 100/200 Output
S 127/220 Input, 127/220 Output
NOTE 1
NOTE 2
NOTE 2
NOTE 4
NOTE 6
NOTE 6
NOTE 5
Figure 32. No External Bypass (L1, L2, N), Non-Isolated Output, and Split-Phase Power Modules
S 200 Input, 200 Output
S 208 Input, 208 Output
S 220 Input, 220 Output
S 230 Input, 230 Output
S 240 Input, 240 Output
NOTE 1
NOTE 2
NOTE 2
NOTE 4
NOTE 6
NOTE 6
NOTE 5
Figure 33. No External Bypass (L1, L2), Non-Isolated Output, and Universal Power Modules
