Powerware 9170 - Page 57

UPS Electrical Installation
49
Powerware
®
9170
+
UPS User’s Guide S Rev B www.powerware.com
S 220 Input, 220 Output
S 230 Input, 230 Output
S 240 Input, 240 Output
NOTE 1
NOTE 2
NOTE 2
NOTE 4
NOTE 6
NOTE 6
NOTE 5
Figure 34. No External Bypass (L1, N), Non-Isolated Output, and Universal Power Modules
