Powtran PI500A Series User Manual

Appendix IV
97
Appendix IV
3
VCC
Power
7
RREST
ARM reset
4
Reserved
Reserve
8
GND
Power ground
Table V-3:PC communication terminal function
IV-2-3 LED Light function
LEDlight
Function definition
Description
Green
Power light
If DP card and drive interfaces connected, the inverter after
power LED should be in the steady state
Red
DP CARDS and
frequency converter
serial port connect
light
DP Card and inverter connected to the normal state of the
LED is lit, flashing indicates the connection is intermittent
(for interference), and drive off when a serial connection is
unsuccessful (You can check the baud rate setting)
Yellow
DP card and
Profibusmain
connection
indicator light
DP Profibus master card and connect normal state of the
indicator is lit. flashing indicates the connection is
intermittent (for interference), and Profibus master is off
when connection is unsuccessful (you can check the slave
address, data formats, and Profibus cable )
Table V-4:LED light function description
