Powtran PI500A Series User Manual

Chapter 6 Troubleshooting
65
Chapter 6
No.
Fault ID
Failure type
Possible causes
Solutions
overspeed detection
parameter(F8.13, F8.14) is
unreasonable.
parameters
45
Err.45
Motor
overtemperat
ure fault
1.the wiring of temperature
sensor is loose
2.the motor temperature is too
high
1.detect the wiring of
temperature sensor wiring and
eliminate fault.
2.decrease carrier frequency or
take other cooling measures to
cool motor
51
Err.51
Initial
position
error
the deviation between the
motor parameters and the
actual parameters is too large
reconfirm the correct motor
parameters, focus on whether the
rated current is set to too small.
-
COF
Communicati
on
failure
1.Keyboard interface control
board interface；
2.Keyboard or crystal
connector；
3.Control board or keyboard
hardware damage；
4.Keyboard line is too long,
causing the interference.
1．Detection of keyboard
interface, control board interface
is abnorma.
2.Detect keyboard, crystal joints
are abnormal.
3.Replace control board or
keyboard.
4. Consult factory, seek help.
6-2.EMC (Electromagnetic Compatibility)
6-2-1.Definition
Electromagnetic compatibility refers to the ability that the electric equipment runs in an
electromagnetic interference environment and implements its function stably without interferences
on the electromagnetic environment.
6-2-2.EMC standard
In accordance with the requirements of the Chinese national standard GB/T12668.3, the
inverter must comply with the requirements of electromagnetic interference and anti-
electromagnetic interference.
Our existing products adopt the latest international standards: IEC/EN61800-3: 2004
(Adjustable speed electrical Power drive systems Part 3: EMC requirements and specific test
methods), which is equivalent to the Chinese national standards GB/T12668.3. EC/EN61800-3
assesses the inverter in terms of electromagnetic interference and anti-electronic interference.
Electromagnetic interference mainly tests the radiation interference, conduction interference and
harmonics interference on the inverter (necessary for civil inverter).
Anti-electromagnetic interference mainly tests the conduction immunity, radiation immunity,
surge immunity, EFTB(Electrical Fast Transient Burs) immunity, ESD immunity and power low
frequency end immunity (the specific test items includes: 1. Immunity tests of input voltage sag,
interrupt and change; 2.commutation notch immunity; 3. harmonic input immunity ; 4. input
frequency change; 5. input voltage unbalance; 6. input voltage fluctuation). The tests shall be
conducted strictly in accordance with the above requirements of IEC/EN61800-3, and our products
are installed and used according to the guideline of the Section 7.3 and can provide good
electromagnetic compatibility in general industry environment.
6-3.EMC directive
6-3-1.Harmonic effect
The higher harmonics of power supply may damage the inverter. Thus, at some places where
the quality of power system is relatively poor, it is recommended to install AC input reactor.
6-3-2.Electromagnetic interference and installation precautions
