Powtran PI500A Series User Manual

Chapter 2 Standard specifications
8
Chapter 2
PI500 250F4
250
407.9
400
250
PI500 250G4/PI500 280F4
250/280
407.9/457.4
400/449
250/280
PI500 280G4
280
457.4
449
280
PI500 315F4
315
533.2
516
315
PI500 315G4/PI500 355F4
315/355
533.2/623.3
516/570
315/355
PI500 355G4/PI500 400F4
355/400
623.3/706.9
570/650
355/400
PI500 400G4
400
706.9
650
400
AC 3PH 690V±10%
PI500 011G6/ PI500 015F6
11/15
15/20
12/15
11/15
PI500 015G6/ PI500 018F6
15/18.5
20/30
15/20
15/18.5
PI500 018G6/ PI500 022F6
18.5/22
30/35
20/24
18.5/22
PI500 022G6/ PI500 030F6
22/30
35/45
24/33
22/30
PI500 030G6/ PI500 037F6
30/37
45/55
33/41
30/37
PI500 037G6/ PI500 045F6
37/45
55/65
41/50
37/45
PI500 045G6/ PI500 055F6
45/55
65/70
50/62
45/55
PI500 055G6/ PI500 075F6
55/75
70/90
62/85
55/75
PI500 075G6/ PI500 093F6
75/93
90/105
85/102
75/93
PI500 093G6/ PI500 110F6
93/110
105/130
102/125
93/110
PI500 110G6/ PI500 132F6
110/132
130/170
125/150
110/132
PI500 132G6/ PI500 160F6
132/160
170/200
150/175
132/160
PI500 160G6/ PI500 187F6
160/187
200/210
175/198
160/187
PI500 187G6/ PI500 200F6
187/200
210/235
198/215
187/200
PI500 200G6/ PI500 220F6
200/220
235/247
215/245
200/220
PI500 220G6/ PI500 250F6
220/250
247/265
245/260
220/250
PI500 250G6/ PI500 280F6
250/280
265/305
260/299
250/280
PI500 280G6/ PI500 315F6
280/315
305/350
299/330
280/315
PI500 315G6/ PI500 355F6
315/355
350/382
330/374
315/355
PI500 355G6/ PI500 400F6
355/400
382/435
374/410
355/400
PI500 400G6/ PI500 450F6
400/450
435/490
410/465
400/450
Note:
(1)PI500 inverter PI500 132G3/PI500 160F3 to PI500 630G3R/PI500 700F3R with "R"
indicating a DC reactor, such as PI500-160G3R, PI500 160G4R.
(2) The correct frequency converter selection method is: inverter rated output current is more
than or equal to the rated current of motor. The difference between the frequency inverter and the
rated power of the motor generally recommends no more than two power segments;Large
frequency inverter with small motor, must accurately input motor parameters, can avoid motor
overload and damage.
2-2.Standard specifications
Items
Specifications
Power Input
Rated voltage
AC 1PH 220V(-15%)～240V(+10%)
AC 3PH 220V(-15%)～240V(+10%)
AC 3PH 380V(-15%)～440V(+10%)
AC 3PH 480V(-10%)～480V(+10%)
AC 3PH 690V(-10%)～690V(+10%)
Input frequency
50Hz/60Hz
Allowing
fluctuations
Voltage continued
volatility:±10%
Less than 3% of voltage unbalance rate
3%；
Input frequency
fluctuation:±5%；
Distortion satisfy IEC61800-2 standard
