96
Appendix IV
Appendix IV: Instruction of Profitbus DP
communication card
IV-1.Outline
9KDP1 meet the international standard PROFIBUS fieldbus, powtran technology PI500 series
inverter use it together to achieve the drive to become a part of fieldbus complete control of real
fieldbus. Before using this product, please carefully read this manual
IV-2 Terminal function
IV-2-1 DIP switch description
Switch
positio
n No.
Function
I`nstruction
1,2
DP Card and the
drive baud rate
selection
Bit 1
Bit 2
Baud Rate
OFF
OFF
115.2K
OFF
ON
208.3K
ON
OFF
256K
ON
ON
512K
3-8
Profibus-DP
Communication
from the station
address
6 Binary Consisting of 64-bit binary address, more than 64 outside
the address can be set only by function code. The following lists
some slave address and switch settings
Address switch settings
0 00 0000
7 00 0111
20 01 0100
Table V-1:Switch Functions
IV-2-2 Terminal Function
1) External communication terminal J4-6PIN
Termin
al NO
Mark
Function
Terminal
NO
Logo
Function
1
GND
5V power ground
4
TR+
Cable Positive
2
RTS
Request to send signal
5
+5V
5Vpower
3
TR-
Cable negative
6
E
The grounding end
Table V-2:External communication terminal function
2) Upper machine communication interface SW1-8PIN
Terminal
No
Terminal
logo
Function
Terminal
No
Terminal
logo
Function
1
BOOT0
ARM boot selection
5
PC232T
PC 232 communication
Sending side
2
GND
Power ground
6
PC232R
PC 232 communication
receiving side
