68
第
十
章
Chapter 7
Chapter 7 Dimension
7-1.Dimension
7-1-1.Product outside drawing, installation size
Nameplate
Cooling fan
operation
panel
Upper cove plate
Upper cover plate
retaining screw
Cable inlet
Air duct inlet
Figure 7-1: 15kW G3 above Product outside drawing, installation dimension
7-1-2.PI500 series
A
B
H1
D1
D
W
H
E
d
NOTE:0.75～4kW G3 support Rail installation
Figure 7-2:0.75～4kW G3Dimension
