Powtran PI500A Series User Manual

Chapter 7 Dimension
76
Chapter 7
Iron shell landing installation series
Power rating
Output
power (kW)
Dimension (mm)
Installation(mm)
Weight
（kg）
H
W
D
D1
A
B
d
PI500 450F3R
450
/
1200
600
612
680
550
17
/
PI500 450G3R/500F3R
450/500
PI500 500G3R/560F3R
500/560
PI500 560G3R/630F3R
560/630
PI500 630G3R/700F3R
630/700
Note: With the letter "R" means with a DC reactor; product installation rings screw height
dimensions: H1 + 15mm.
7-1-4.Keypad dimension drawing
PI500 keyboard size:
65
100
189
37
52
65
6.5
2-M3
20.5
17
17
Figure 7-10:PI500 keyboard size (size: mm)
