Chapter 7 Dimension
77
Chapter 7
PI500 keyboard size chart:
90
135
52
19.5
87
65
5-? 4.2
90°
81
82
127
126
22
Figure 7-11:keyboard size chart (size: mm)
PI500 keyboard installation opening size:
82
126.5
84
129
4-R9
T=1.0~1.5mm
T=1.0~1.5mm
Installation
panel
Installation
panel
Outside installation panel open
inlet dimension
Inside installation panel open
inlet dimension
Figure 7-12:keyboard installation opening size chart (size: mm)
