Powtran PI500A Series User Manual

Chapter 5 Function parameter
50
Chapter 5
3: Panel potentiometer setting
4: High-speed pulse setting
5: Communications reference
6: MIN (AI1, AI2)
7: MAX (AI1, AI2)
8.
High-speed pulse setting
300
FA.02
Torque figures setunder torque
control mode
-200.0% to 200.0%
150%
☆
301
FA.03
Torque control acceleration time
0.00s to 650.00s
0.00s
☆
302
FA.04
Torque control deceleration time
0.00s to 650.00s
0.00s
☆
303
FA.05
Torque control forward maximum
frequency
0.00Hz to F0.19(maximum
frequency)
50.00Hz
☆
304
FA.06
Torque control backward
maximum frequency
0.00Hz to F0.19 (maximum
frequency)
50.00Hz
☆
305
FA.07
Torque filter time
0.00s to 10.00s
0.00s
☆
5-1-13.FB Group - Control optimization parameters
No.
Code
Parameter name
Setting range
Factory
setting
Chan-
ge
306
FB.00
Fast current limiting manner
0: Invalid 1: enable
1
☆
307
FB.01
Under-voltage point setting
50.0% to 140.0%
100.0%
☆
308
FB.02
Over-voltage point setting
200.0V to 2500.0V
810V
☆
309
FB.03
Deadband compensation mode
selection
0: no compensation
1: compensation mode 1
2: compensation mode 2
1
☆
310
FB.04
Current
detection
compensation
0 to 100
5
☆
311
FB.05
Vector optimization without PG
mode selection
0:
no optimization
1: optimization mode 1
2: optimization mode 2
1
☆
312
FB.06
Upper limiting frequency for
DPWM switching
0.00Hz to 15.00Hz
12.00H
z
☆
313
FB.07
PWM modulation manner
0:asynchronous；1:synchronous
0
☆
314
FB.08
Random PWM depth
0: Invalid
1 to 10: PWM carrier frequency
random depth
0
☆
315
FB.
09
Deadband time adjustment
100% to 200%
150%
☆
5-1-14.FC Group - Extended parameter group
No.
Code
Parameter name
Setting range
Factory
setting
Chan-
ge
316
FC.00
Undefined
317
FC.01
Proportional linkage coefficient
0.00 to 10.00
0
☆
318
FC.02
PIDstart deviation
0.0 to 100.0
0
☆
5-1-15.E0 Group - Wobbulate, fixed-length and counting
