Powtran PI500A Series User Manual

Chapter 7 Dimension
74
Chapter 7
Iron shell landing installation series
Power rating
Output
power
(kW)
Dimension (mm)
Installation(mm)
Weight
（kg）
H
H1
W
D
D1
A
B
d
PI500 132G3R/160F3R
132/160
995
1020
400
360
368
350
270
13*18
115
PI500 132G4R/160F4R
PI500 160G3R/187F3R
160/187
1230
1260
480
390
398
400
200
13
153
PI500 187G3R/200F3R
187/200
PI500 200G3R/220F3R
200/220
PI500 220G3R
220
PI500 160G4R/187F4R
160/187
PI500 187G4R/200F4R
187/200
PI500 200G4R/220F4R
200/220
PI500 220G4R
220
PI500 250F3R
250
1419
1460
560
410
418
500
310
13
205
PI500 250G3R/280F3R
250/280
PI500 280G3R
280
PI500 250F4R
250
PI500 250G4R/280F4R
250/280
PI500 280G4R
280
PI500 315F3R
315
1419
1460
705
410
418
620
240
13
249.4
PI500 315G3R/355F3R
315/355
PI500 355G3R/400F3R
355/400
PI500 400G3R
400
PI500 315F4R
315
PI500 315G4R/355F4R
315/355
PI500 355G4R/400F4R
355/400
PI500 400G4R
400
Note: With the letter "R" means with a DC reactor; product installation rings screw height
dimensions: H1 + 15mm.
a
b
h1
h2
h3
H
W
d
d
d1
e
Knocking down holes and enlarging plans
15:1
D
Figure 7-8:132～400kW G3(With DC reactor and base) Wall hanging dimensions
