Powtran PI500A Series User Manual

Appendix I
90
Appendix I
(torque upper limit digital setting).
Control command is input to the inverter: (write only)
Command word address
Command function
2000
0001: Forward run
0002: Reverse run
0003: Forward Jog
0004: Reverse Jog
0005: Free stop
0006: Deceleration and stop
0007: Fault reset
Inverter read status: (read-only)
Status word address
Status word function
3000
0001: Forward run
0002: Reverse run
0003: Stop
Parameter lock password verification: (If the return code is 8888H, it indicates that password
verification is passed)
Password address
Enter password
C000
*****
Digital output terminal control: (write only)
Command address
Command content
2001
BIT0: SPA output control
BIT1: RELAY2 output control
BIT2 RELAY1 output control
BIT3: Manufacturer reserves the undefined
BIT4: SPB switching quantity output control
Analog output DA1 control: (write only)
Command address
Command content
2002
0 to 7FFF indicates 0％ to 100％
Analog output DA2 control: (write only)
Command address
Command content
2003
0 to 7FFF indicates 0％ to 100％
SPB high-speed pulse output control: (write only)
Command address
Command content
2004
0 to 7FFF indicates 0％ to 100％
Inverter fault description:
Inverter fault address:
Inverter fault information:
8000
0000: No fault
0001: Inverter unit protection
0002: Acceleration overcurrent
0003: Deceleration overcurrent
0004: Constant speed overcurrent
0005: Acceleration overvoltage
0006: Deceleration overvoltage
0007: Constant speed overvoltage
