Powtran PI500A Series User Manual

Appendix II
94
Appendix II
Wire gauge
>22AWG(0.3247mm²)
Maximum frequency
500kHz
Input differential signal amplitude
≤7V
PI500_PG3 terminal description
No.
Label
No.
Description
No.
Label
No.
Description
1
A+
Encoder output A signal positive
9
V+
Encoder output V signal positive
2
A-
Encoder output A signal negative
10
V-
Encoder output V signal negative
3
B+
Encoder output B signal positive
11
W+
Encoder output W signal positive
4
B-
Encoder output B signal negative
12
W-
Encoder output W signal negative
5
Z+
Encoder output Z signal positive
13
+5V
Output 15V/100mA power
6
Z-
Encoder output Z signal negative
14
GND
Power ground
7
U+
Encoder output U signal positive
15
-
8
U-
Encoder output U signal negative
Rotational transformer PG card(PI500_ PG4)
PI500_PG4 specifications
User interface
Terminal block
Swappable
NO
Wire gauge
>22AWG(0.3247mm²)
Resolution
12-bit
Excitation frequency
10kHz
VRMS
7V
VP-P
3.15±27%
PI500_PG4 terminal description
No.
Label
No.
Description
No
Label
No.
Description
1
EXC1
Rotary transformer excitation
negative
4
SINLO
Rotary transformer feedback
SINLO negative
2
EXC
Rotary transformer excitation
positive
5
COS
Rotary transformer feedback COS
positive
3
SIN
Rotary transformer feedback SIN
positive
6
COSLO
Rotary transformer feedback
COSLO negative
OC PG card(PI500_PG5)
PI500_PG5 specifications
User interface
Terminal block
Spacing
3.5mm
Screw
Slotted
Swappable
NO
Wire gauge
16-26AWG(1.318~0.1281mm²)
Maximum frequency
100KHz
PI500_PG5 terminal description
No.
Label
No.
Description
No.
Label
No.
Description
1
A
Encoder output A signal
6
A0
PG card 1:1 feedback output A signal
2
B
Encoder output B signal
7
B0
PG card 1:1 feedback output B signal
3
Z
Encoder output Z signal
8
Z0
PG card 1:1 feedback output Z signal
4
15V
Output 15V/100mA power
9
PE
Shielding terminal
