PPT VISION, Inc. Cable Reference
A-Series Hardware Guide
5-9
*IMPORTANT NOTE: The power connection terminal numbers for the Terminal Block and the Unterminated cable wire
numbers are not the same. Use caution when connecting power.
7
8
White/Green
Green/White
Strobe Output +
Strobe Output -
9
10
White/Blue
Blue/White
Output 1 +
Output 1 -
11
12
White/Violet
Violet/White
Output 2 +
Output 2 -
13
14
White/Grey
Grey/White
Output 3 +
Output 3 -
15
16
White/Pink
Pink/White
Output 4 +
Output 4 -
17
18
White/Tan
Tan/White
24 VDC Power + (See Note*)
24 VDC Power +
19
20
Tan/Brown
Brown/Tan
24 VDC Power -
24 VDC Power -
21
22
Tan/Orange
Orange/Tan
24 VDC Power Ground
24 VDC Power Ground
23
24
25
Tan/Yellow
Yellow/Tan
Tan/Pink
Serial Transmit
Serial Receive
Serial Ground
Micro D Sub
Connector Pin
Wire Color Signal Name
