PPT Vision A-Series - Terminal Block Connection Table (Except A10)

PPT VISION, Inc. Cable Reference
A-Series Hardware Guide
5-7
Terminal Block Connection Table (except A10)
*IMPORTANT NOTE: The power connection terminal numbers for the Terminal Block and the Unterminated cable wire
numbers are not the same. Use caution when connecting power.
Terminal Number Signal Name
1
2
Trigger Input +
Trigger Input -
3
4
Input 1 and Shift Event+
Input 1 and Shift Event -
5
6
Input 2 and Event Input +
Input 2 and Event Input -
7
8
Strobe Output +
Strobe Output -
9
10
Output 1 +
Output 1 -
11
12
Output 2 +
Output 2 -
13
14
Output 3 +
Output 3 -
15
16
Output 4 +
Output 4 -
17 24 VDC Power + (See
Note*)
18 24 VDC Power -
19 24 VDC Power Ground
