Loop Leader PD6600 Series Loop-Powered Meters Instruction Manual
20
Available Unit Classes and Units
The meter has six available preprogrammed unit
classes, volume, height, temperature, pressure,
weight, and rate. Each unit class has the following
available units to choose from:
BBL
BUSH
HECtL
AF
INCH
FEET
FT-IN
~F
Pressure Units (PRESSURE)
PSI
InHg
mmHg
Kg/CM2
Kilograms per square centimeter
Kilograms per square meter
PA
hPA
KPA
gm
tonnE
oz
/SECOND
Gallons per time unit (T)
Imperial gallons per time unit (T)
Cubic meters per time unit (T)
Barrels per time unit (T)
Bushels per time unit (T)
Cubic Yards per time unit (T)
Cubic Feet per time unit (T)
cuIn/
Cubic Inches per time unit (T)
Liquid barrels per time unit (T)
Beer barrels per time unit (T)
Hectoliter per time unit (T)
Acre-Foot per time unit (T)
CUSTOM/
Custom unit per time unit (T)
Setting Custom Units (CUSTOM)
When the desired unit class or unit of measure within a
class is not available, a custom unit may be programmed.
Select the CUSTOM menu (or CUSTOM unit within a unit
class) in order to enter a custom unit name.
Text values are set using the Right and Up arrow but-
tons. Press Right arrow to select next character and
Up arrow to increment character value. The selected
character will flash. Press and hold the Up or Right
arrow buttons to auto-increment or decrement the
character. Press Enter to accept the character.
Notes:
• Press and hold the Right arrow while no character is be-
ing edited to erase all characters to the right of the flash-
ing character
• Press and hold Up or Right arrow to auto-increment or
decrement a selected character.
