Troubleshooting
This product is a highly sophisticated instrument with
an extensive list of features and capabilities. If the
front panel buttons are used to program the meter, it
can be a difficult task to keep everything straight. That
is why we strongly recommend the use of the free
MeterView XL
software for all programming activities.
A cable is provided to use the MeterView XL software
for programming the meter.
If you have programmed the meter with the front
panel buttons and it is not working as intended, try
re-programming the meter using the MeterView XL
software.
Reset Meter to Factory Defaults
When the parameters have been changed in a way
that is difficult to determine what’s happening, it might
be better to start the setup process from the factory
defaults. This can be accomplished using MeterView
XL software or with the front panel buttons.
To load factory defaults:
Press the Menu button to enter Programming Mode.
Press the Right Arrow button twice and press Enter
to access the Advanced menu.
Press the Up-Arrow button and press Enter to ac-
cess the System menu.
Press the Right Arrow button and press Enter to
access the Default menu.
Press Enter twice in quick succession. The meter will
load default settings and restart.
Determining Software Version
To determine the software version of a meter:
1. Press the Menu button to enter Program-
ming Mode.
2. Press the Up-Arrow button twice and press
Enter to access the Advanced menu.
3. Press the Up-Arrow button and press Enter
to access the System menu.
4. Press the Up-Arrow button twice and press
Enter to access the Info menu.
5. Press the Right-Arrow button to cycle
through the meter information. When done,
press the Menu button to return to the previ-
ous menu or press & hold Menu to exit to
Run mode.
SYSTEM
SYSTM
AOUTCAL
SYSTM
DEFAULT
LOAD?
DEFAULT
RESET
DFAULT?
Meter Loads
Default Settings
and Restarts
To Next Page
