Loop Leader PD6600 Series Loop-Powered Meters Instruction Manual
41
Factory Default Settings
The following table shows the factory setting for most
of the programmable parameters on the meter.
Parameter
Display
Default Setting
Input Menu
Unit Class
UNITS
Volume
Unit of Measure
UNIT
Gallons
Input 1
INP 1
4.000 mA
Display 1
DSP 1
0.00
Input 2
INP 2
20.000 mA
Display 2
DSP 2
100.00
Output Menu
Open Collector
Output 1
OUTPUT 1
Disabled
Pulse Factor
FACTOR
1.0
Test Frequency
FREQ
100
Alarm
ALARM
PV
Alarm Action
ACTION
AUTO
Set Point
SET
20.00
Reset Point
RESET
10.00
Alarm On Delay
DELAY ON
0 seconds
Alarm Off Delay
DELAY OFF
0 seconds
Alarm Fail-safe
FAILSAFE
OFF
Red LED
RED
ON
Flash PV
FLASH
ON
Alarm Message
MSG
ON
Message Text
MSG EDIT
ALARM 1
Timer Off Delay
OFF.DLAY
1 minute
Timer On Time
ON TIME
1 second
Timer Mode
MODE
Continuous
Open Collector
Output 2
OUTPUT 2
Disabled
Set Point
SET
40.00
Reset Point
RESET
30.00
Message Text
MSG EDIT
ALARM 2
Relay Output 1
RELAY 1
Disabled
Alarm
ALARM
PV
Alarm Action
ACTION
AUTO
Set Point
SET
70.00
Reset Point
RESET
60.00
Alarm On Delay
DELAY ON
0 seconds
Alarm Off Delay
DELAY OFF
0 seconds
Alarm Fail-safe
FAILSAFE
OFF
Red LED
RED
ON
Flash PV
FLASH
ON
Alarm Message
MSG
ON
Message Text
MSG EDIT
ALARM 3
Pump Ctrl On
ON
70.00
Parameter Display Default Setting
Pump Ctrl Off
OFF
60.00
Pump Ctrl On
Delay
DELAY ON
0 seconds
Pump Ctrl Off
Delay
DELAY OFF
0 seconds
Pump Alt On 1
ON 1
70.00
Pump Alt Off 1
OFF 1
60.00
Pump Alt On 2
ON 2
90.00
Pump Alt Off 2
OFF 2
80.00
Pump Alt On
Delay 1
DELAY 1 ON
0 seconds
Pump Alt Off
Delay 1
DELAY 1 OFF
0 seconds
Pump Alt On
Delay 2
DELAY 2 ON
0 seconds
Pump Alt Off
Delay 2
DELAY 2 OFF
0 seconds
Timer Off Delay
OFF.DLAY
1 minute
Timer On Time
ON TIME
1 second
Timer Mode
MODE
Continuous
Relay Output 2
RELAY 2
Disabled
4-20 mA Output
4-20 mA
PV
Advanced Menu
Signal
Conditioning
Function
FUNCTION
Linear (2 pts)
Low Cutoff
CUTOFF
Enabled: 0
Filter
FILTER
2.0 seconds
Filter Bypass
BYPAS
0.4 PCT
Password
PASSWRD
00000 (Un-
locked)
Function Key 1
F1
Display
Function Key 2
F2
Reset
Function Key 3
F3
Acknowledge
Digital Input
DI
Acknowledge
Function Key
Hint Feature
HINT
Disabled
Dual-Scale
PV 2
Disabled
Backlight
BACKLIGHT
Enabled
Display Menu
Unit of Measure
UNITS
Gallons
Decimal Point
Location
DEC.PT
2
Comma
COMMA
Enabled
Top Line
TOP
PV
Bottom Line
BOTTOM
Units
Signal
Conditioning
Function
FUNCTION
Linear (2 pts)
Low Cutoff
CUTOFF
Enabled: 0
