Troubleshooting Tips
Symptom
Check/Action
No display at all
1. Check that the 4-20 mA current
loop is providing at least 3.5 mA
to the meter.
2. Check that the voltage drop of all
devices connected to the 4-20
mA current loop does not exceed
the max rating of the loop power
supply.
Not able to
change setup or
programming,
LOCKED is
displayed
Meter is password-protected, enter
correct five-digit password to unlock.
Meter display
flashes:
1. 99999
2. -9999
Check that the number of digits
required for the scaled value does not
exceed the maximum digits for the
display line. If it does, try adjusting the
decimal point location for less
precision or changing the PV display
to the bottom line.
Display is
unstable
Check:
1. Input signal stability and value.
2. Display scaling vs. input signal.
3. Filter and bypass values
(increase).
Display response
is too slow
Check filter and bypass values
Display reading is
not accurate
Check:
1. Signal input conditioner selected:
Linear, square root, etc.
2. Scaling or calibration
Display does not
respond to input
changes, reading
a fixed number
Check display assignment. It might be
displaying max, min, or set point.
Display shows:
1. MAX and a
number
2. MIN and a
number
Press Menu to exit max/min display
readings.
Relay operation is
reversed
Check fail-safe settings in Output
menu
Relays do not
respond to signal
Check:
1. Relay action in Output menu
2. Set and reset points
3. Check manual control menu
If the display
locks up or the
meter does not
respond at all
Cycle the power to reboot the
microprocessor.
Other symptoms
not described
above
Call Technical Support for assistance.
Note: Certain sequences of events can cause unexpected
results. To solve these issues, it is best to start fresh from
factory defaults and use the manual as a step by step
programming guide, rather than a random approach to
programming. See Reset Meter to Factory Defaults on page
40 for details on resetting the meter to factory defaults. In
addition, for best results, we recommend using the free
MeterView XL software for all programming needs.
