Loop Leader PD6600 Series Loop-Powered Meters Instruction Manual
37
Viewing System Information
(
INFO)
System information, such as software number,
software version, model number, and system tag,
may be viewed in the INFO menu. Press the Right
Arrow button to cycle through all available meter
information. Press Menu to go back to the previous
menu.
Calibrating the Internal mA
Reference (
ICAL)
The meter is factory calibrated prior to shipment to display
0.00 to 100.00, which corresponds to the 4-20 mA input.
The calibration equipment is traceable to NIST standards.
The use of calibrated signal sources is necessary to
calibrate the internal source of the meter. The meter’s
internal source is what allows the user to scale the
meter without applying a signal.
Check calibration of the meter at least every
12 months.
Note: Allow the meter to warm up for at least
15 minutes before performing the internal source
calibration procedure.
The Internal Calibration menu is part of the Advanced
menu. Internal Calibration is performed as follows:
Press the Menu button to enter Programming Mode.
Press the Up-Arrow button twice and press Enter to
access the Advanced menu.
Press the Up-Arrow button and press Enter to
access the System menu.
Press the Up-Arrow button and press Enter to
access the ICAL menu.
The meter displays low input current message
(4.000 mA). Apply a 4 mA signal and press Enter.
The display flashes for a moment while the meter is
accepting the low input signal.
After the display stops flashing, the display moves to
the high input calibration (20.000 mA). Apply the high
input signal and press Enter. The display will flash
again while the meter is accepting the high input
signal.
SYSTM
ICAL
ICAL
4.000 mA
Display
Flashes While
Accepting Input
ICAL
20.000 mA
Display
Flashes While
Accepting Input
Apply 4-mA
Signal
Apply 20-mA
Signal
To Next Page
