• DVM meter • Torque
1
Wrenches: 9 in lbs to 100 in - lbs
(83 ft-lbs)
• AC
2
Clamp-on averting current meter • DVM Multimeter
• Belt tension gauge – OTC Tools Model #:
6673
• Drive Belt tension Gauge (Kent-Moore BT-
33-73-F
• 2 Running belt tension gauges (Precor
PN: PPP000000020007101)
• Compatible HR
3
chest strap or Polar HRM
simulator xmitter (Precor PN:
PPP000000020045101)
• 12 " wonder bar • Vacuum cleaner (recommend ESD safe
model)
• ESD wrist strap
Supplies
• Super Lube Gel with Teflon by Permatex • Cleaning rags
• Mobil 1, NLGI 2 Teflon Synthetic Grease • Cleaner Degreaser (see )
• Loctite 243 Blue Medium Strength Thread-
locker
• Cable ties (1- 3/4", 3", 4" lengths)
Specification Summary
Fastener Torque Specification
System component fastener torque specification:
System Component Specification
RF
4
coax connector 2.4 in-lbs (0.271 Nm)
Display mounting fasteners 180 in-lbs (20 Nm
1
Torque is a measure of the force that can cause an object to rotate about an axis. Bolt/nut
example: 5 NM torque is equivalent to 5 newton's of force applied one meter from the center of
the bolt, 6 ft-lb is equivalent to 6 lbs of force applied 1 foot away from the center of the bolt.
2
Alternating Current: electric current which periodically reverses direction between positive
and negative polarity.
3
Heart Rate
4
Radio Frequency: Identifies electromagnetic signals with frequency spectrum between the 3
kHz (3,000 hertz) to 300 GHz (300 billion hertz) range.
Contact Precor Customer Support at support@precor.com or 800.786.8404 with
any questions.
Page 9
