Running Belt Troubleshooting
The TRM700/800 series treadmill provide the following diagnostic tools to help isolate and
resolve running belt issues:
l Belt Rating parameter that indicates the condition of the running belt.
l Diagnostics Belt Speed Test can be used to monitor the drive motor load current
(Higher than typical motor current indicates a worn belt/deck condition)
l On P62, P80, and P82 consoles, the Club Setting > Maintenance menu provides addi-
tional diagnostics to help determine the condition of the running belt and deck: Recom-
mended Action, Operating Condition. and Belt Rating status information.
Belt Rating Information
l Belt Rating indicates the condition of the belt ranging from 10 (New) to 0 (Fully worn):
o
10 - New Belt
o
1 or 0:- Fully worn, replace the belt
l Belt Rating parameter can be viewed in the following menus:
o
P10, P30, P30i and P31: Information Display (65): > Belt Rating
o
P62, P80, and P82: Club Settings (5651565) > Maintenance menu > Belt Rat-
ing
l The amount of belt/deck friction increases as the belt rating number approaches 0. As
the friction increases so does the amount of motor current required to move the belt.Typ-
ically cleaning the belt and deck will reduce friction causing the drive motor to work less
resulting in a higher belt rating number.
l Belt rating is an algorithm that incorporates the average drive motor load current (and
other parameters) of the last 100 5.5 mph to 12.5 mph workouts to derive the belt rating
wear number.
l P10, P30, P30i and P31: The Belt Rating menu is also used to clear the history and
reset the belt rating number of averages to 10. The service tech should reset the belt rat-
ing after each belt/deck replacement (hold QUICKSTART down).
l When the belt rating reaches 1 or 0, the ASL
1
(Active Status Light)state will go to the
blue flashing state.
l The ASL will automatically change back to blue solid when the belt rating has moved
above 1 (2 thru 10).
Procedure
1. Go to the console service menu and read the Belt Rating parameter:
P10, P30, P30i and P31 consoles: Information Displayy (65) > Belt Rating
1
Active Status Light: Service and maintenance status light.
Contact Precor Customer Support at support@precor.com or 800.786.8404 with
any questions.
Page 210
7 Troubleshooting
System Troubleshooting Procedures
