System Component Specification
Set screws 300 in-lbs (34 Nm)
Plastite screw fasteners 20 in-lbs (2.3 Nm)
Flathead screws 25 in-lbs (2.8 Nm)
Deck front fasteners 27-33 in-lbs (3.1-3.7 Nm)
Deck rear fasteners 50-55 in-lbs (5.6-(6.2 Nm)
Lift Motor Calibration gap 1 1/8 in - 1 3/16 in (2.8 cm - 3.0 cm)
BeltTension Specification
.Belt tension specification:
System Component Specification
Drive Belt Tension New Belt
(1)
100-120 lbs (45-54 kgs)
Drive Belt Tension Used Belt
(1)
80-90 lbs (36-41 kgs)
Drive Motor fasteners 204 in-lbs (17 ft-lbs, 23 N-m)
Ammeraal brand running belt tension (gauge/-
percent)
3.75 (0.75%)
(2)
Forbo brand running belt tension (gauge/percent) 3.55 (0.55%)
(2)
(1)New belt tension applies to new belt first time installations. Used belt tension applies to
reinstalling an existing belt or re-tensioning an existing used belt.
(2)Referenced to 3.0 (0.0%).
Bolt Grade Identification
Bolt grade markings are used to categorize bolts according to the bolt material, manufacturing
process, and mechanical properties.The grade of the bolt is stamped on the head of the bolt.
US SAE bolts: The bolt grade markings are determined by the number of the lines stamped
on the head of the bolt. The number of lines is always two less than the grade of the bolt.
Count the lines, add two, and you can determine the grade of the bolt.
Metric bolts: On metric bolts, the bolt grade is identified by a bolt grade number stamped on
the head of the bolt.
CAUTION:Always replace bolts with the same grade bolt. If you don’t know the
grade of the replacement bolt DO NOT USE THE BOLT.
Contact Precor Customer Support at support@precor.com or 800.786.8404 with
any questions.
Page 10
