Trim End Cap Covers Replacement
Trim End Cap Covers Replacement
ID Description
Trim End Cap - left
Trim End Cap - right
Removal Instructions
Repeat procedure for both the left and right end cap covers.
1. Remove the hood cover, see "Hood Cover Replacement" on page72.
2. Remove the left and right trim landing covers, see "Covers and Panels Replacement"
on page70.
3.
Remove the three #3 Phillips left and right trim end cap cover fastener screws.
One fastener on the top, one fastener on the end, and one fastener on the bottom.
Retain part(s) and/or fastener(s) for installation.
TIP: Use a short stub #3 Phillips screwdriver to remove the bottom end cap fastener.
Contact Precor Customer Support at support@precor.com or 800.786.8404 with
any questions.
Page 78
6 Replacement Procedures
Covers and Panels Replacement
