ASL State DESCRIPTION
Blue Solid Normal operation Indicates that the ASL has not detected any logged
error codes.
Blue Pulsing Preventative maintenance reminder.
Treadmills: A belt rating of 0 or 1 will cause a blue pulsing ASL light indic-
ating that there is a problem with the running belt/deck and is in need of
servicing or replacement.
Ellipticals: The maintenance counter starts at 1000 hours and counts
down the active use hours to 0. When the counter reaches zero hours,
the ASL will begin pulsing blue indicating preventative maintenance is
due.
Yellow Solid Indicates an error has occurred, was self-corrected and the machine can
be used. The fault can be cleared.
Yellow Pulsing There is a current non-recoverable fault condition, there is a loss of a
major function and the machine is out-of-service. Machine service is
required.
ASL Settings and Functions
Setting the ASL light brightness level
The ASL Light Brightness level settings are HIGH, MEDIUM, and LOW. On P10, P30, P30i
and P31 consoles, the light brightness level can be switched OFF.
l On P10, P30, P30i and P31 consoles, the OFF setting switches the ASL light brightness
OFF for all ASL state conditions. Setting the ASL Light Brightness OFF only switches
the ASLlight brightness OFF and not the ASL active status functionality.
l Regardless of the brightness level setting (including OFF), you can view the current
ASL state (blue, yellow, etc.) in the service access menus, see "Viewing the current
ASL state" on the next page.
P10, P30, P30i and P31 consoles:
Access Hardware Validation (51765761) > AS LIGHT BRIGHTNESS > select HIGH, MED,
LOW, or OFF.
P62, P80, and P82 consoles:
Access Hardware Validation (51765761) > Maintenance menu > AS LIGHT
BRIGHTNESS > select HIGH, MED, or LOW.
Contact Precor Customer Support at support@precor.com or 800.786.8404 with
any questions.
Page 177
7 Troubleshooting
Active Status Light (ASL)
