DIAGNOSTIC TEST TEST DESCRIPTION
KEYBOARD TEST
An illuminated LED map of the function keys will be shown. Press
each individual key and verify that the corresponding LED extin-
guishes. Press and hold BACK to exit the test.
PVS
1
KEY TEST Not used, OEM test.
HEART RATE
Tests the unfiltered, filtered, and pulse heart rate. Grasp the grips
to test the hand held heart rate. Use a Polar heart rate simulator to
test the wireless heart rate. Press the BACK button to exit this
test.
ACTIVE STATUS
LIGHT
(1)
The current ASL
2
status light state (blue. pulsing blue, yellow, &
pulsing yellow).
AS LIGHT
BRIGHTNESS
(1)
Sets the ASL light brightness level and ON/OFF state:HIGH.
MED, LOW, and ON/OFF.
MC
3
LIGHT Shows current state of MC LED-Hold Quick Start to reset.
BELT SPEED TEST
menu: MACHINE TEST > BELT SPEED TEST
Tests belt operating condition in 0.1 speed increments
Test parameters:
• AMPS IN: Treadmill input Current.
• VOLTS IN: Treadmill input Voltage
• VBUSS: Treadmill internal buss Voltage
• AMPS MTR: Current supplied to the drive motor.
AUTO STOP TEST
menu: MACHINE TEST > AUTO STOP TEST
Test parameters;
• Status - Exerciser detected on or off the running belt.
• Step Count - Average # of footplants. Footplant averaging delay
reset with each speed change.
.
INCLINE TEST
menu: MACHINE TEST > INCLINE TEST
Test parameters;
• A/D - lift motor incline position potentiometer A/D number.
1
Personal Viewing System display.
2
Active Status Light: Service and maintenance status light.
3
Motor controller or motor controller module
Contact Precor Customer Support at support@precor.com or 800.786.8404 with
any questions.
Page 31
4 Standard Service Menus
LED Console Standard Service Menus
