Precor SPINNER CHRONO POWER User Manual

13. If the axle nuts were not previously tightened to specification, tighten the left and right
axle nuts torque to 29.5 ft-lbs (40 Nm).
14. Adjust the generator belt tension to 1/4 in (6.5 mm) belt deflection, see "Generator
Belt Tension Adjustment" on page35 .
15. Install the left and right brake pads and adjust the brake pad gap to specification, see
"Brake Pad Replacement" on page52.
16. Replace front and rear belt guard covers in reverse order, see "Belt Guard Cover
Replacement" on page47.
17. Verify the bike operation per "Operation Verification Checklist" on page14 and return
to service.
Contact Precor Customer Support at support@precor.com or 800.786.8404 with
any questions.
Page 97
5 Replacement Procedures
Drive Belt, Generator Belt, and Flywheel Replacement
