either revert back to blue (or pulsing blue), or require the operator to do a manual
reset from the service menu.
ASL States
The ASL utilizes a combination of blue and yellow lights to indicate the current operational
machine status.
ASL State DESCRIPTION
OFF The unit is powered OFF when the pedals are stopped or there is an
ASL hard failure. The ASL brightness can be set to OFF.
Blue Solid Normal operation Indicates that the ASL has not detected any system
error codes.
Blue Pulsing Preventative maintenance reminder
The maintenance counter starts at 1000 miles and counts down the act-
ive use hours to 0. When the counter reaches zero hours, the ASL will
begin pulsing blue indicating preventative maintenance is due.
Yellow Solid Indicates an error has occurred, was self-corrected and the machine
can be used. The fault can be manually cleared or will auto-reset if no
new detected errors after 50 miles of use.
Yellow Pulsing There is a current non-recoverable fault condition, there is a loss of a
major function and the machine is out-of-service. Machine service is
required.
ASL Setup and Test
ASL Setup and test
Menu Path: service menu > select ASL SETUP
Range: ON, OFF, YELLOW ON, BLUE ON
ASL SETUP is used to switch ON or OFF the ASL indicator light for all state conditions and
to test the ASL yellow and blue LEDs.
ASL SETUP DESCRIPTION
ON Normal ASL operation, Indicates all maintenance state conditions: solid
blue, pulsing blue, solid yellow, and pulsing yellow.
Contact Precor Customer Support at support@precor.com or 800.786.8404 with
any questions.
Page 153
6 Troubleshooting
Active Status Light (ASL)
