Rear Stabilizer Replacement
About
This procedure provides instruction to remove and install the Rear Stabilizer.
Specifications
System Component Specification
Stabilizer fastener Torque
1
15.6 ft-lbs (21 N•m)
Procedure
Review entire procedure before starting.
Removal Instructions
1. Place a soft mat under the bike frame and stand the bike frame on its rear resting on
the front stabilizer and handlebar.
2. Remove the two rear stabilizer leveling feet (2x). Retain stabilizer leveling feet for
installation.
1
Torque is a measure of the force that can cause an object to rotate about an axis. Bolt/nut
example: 5 NM torque is equivalent to 5 newton's of force applied one meter from the center
of the bolt, 6 ft-lb is equivalent to 6 lbs of force applied 1 foot away from the center of the
bolt.
Contact Precor Customer Support at support@precor.com or 800.786.8404 with
any questions.
Page 140
5 Replacement Procedures
Stabilizer Replacement
