2. Position the front stabilizer onto the frame and secure using the two 6 mm hex key sta-
bilizer mounting bolts (2x) and washers (2x) , torque to 15.6 ft-lbs (21 N•m).
CAUTION:Do not over tighten fasteners. The bolt heads can snap off if over
tightened.
3. Reinstall the two stabilizer leveling feet.
4. Return bike to the upright position.
5. Make sure the bike is level and setting firmly on the floor, see "Bike Leveling Adjust-
ment" on page39.
6. Verify bike operation per the "Operation Verification" on page14 check list and return
to service.
See Also
"Rear Stabilizer Replacement" on the next page
"Bike Leveling Adjustment" on page39
Contact Precor Customer Support at support@precor.com or 800.786.8404 with
any questions.
Page 139
5 Replacement Procedures
Stabilizer Replacement
